类型:高压探头 品牌:美国泰克 型号:P5200 / P5205 /P5210 通道数:2 带宽:2（MHz） 采样率:2（GS/s） 记录长度:2（k） 波形捕获率:1（wfms/s） 外形尺寸:1（mm） 重量:1（kg）
P5200
The P5200 can be used with any oscilloscope and enables users to safely make measurements of floating circuits with their oscilloscope grounded. The P5200 Active Differential Probe converts floating signals to low-voltage ground-referenced signals that can be displayed safely and easily on any ground-referenced oscilloscope.
WARNING: For safe operation, do not use the P5200 High-voltage Differential Probe with oscilloscopes that have floating inputs (isolated inputs), such as the Tektronix TPS2000 Series oscilloscopes and THS700 Series oscilloscopes. The P5200 High-voltage Differential Probe requires an oscilloscope or other measurement instrument with grounded inputs.
P5210
The P5210 is a Differential Probe that is capable of measuring floating voltages up to 5,600 V (DC + pk AC)safely and has a bandwidth up to 50 MHz. It is supplied with two sizes of hook tips and has an overrange visual and audible indicator which warns the user when they are exceeding the linear range of the probe. It can be used with Tektronix TEKPROBE™ interface oscilloscopes directly or with any oscilloscope with the use of the 1103 TEKPROBE® Power Supply.
The P5205 is a 100 MHz Active Differential Probe capable of measuring fast rise times of signals in floating circuits. This 1,300 V differential probe can safely measure voltages in IGBT circuits such as motor drives or power converters. It is specifically designed to operate on Tektronix oscilloscopes with TEKPROBE®interface.
P5200
P5205
