Specifications

Bandwidth

200MHz

Attenuation

1/10

Accuracy

±1%

Input Impedance

500KΩ//7 p F each side ground

Input Voltage

-Differential Input Voltage

±20V

-Common  Mode Voltage

±60V

-Absolute Max．Voltage

(either input to ground)

±60Ｖ

Output Voltage

-Swing(into 50 KΩ load)

±2V

-Offset(t*ical)

＜±2mV

-Source Impedance（t*ical）

50Ω

CMRR（t*ical）

-80 d B @100Hz;-50db@10MHz

Power Requirements

-Standard

6V DC/90m A or 9V DC/70m A mains adaptor

-Options

Removable battery pack or power leads

Length of BNC Lead

125cm

Length of Input Leads

50cm

Weighr

300g

Dimension(L×W×H)

111mm×22mm×14mm

Features:

Bandwidth up to200MHz

0.1m V Sensitivity

Applications:

Telecom Measurement

x DSL Applications

High Speed Power Measurement

Differential Line Tran*itter and Receiver Design
