The MET1117 series are highly accurate, low noise, LDO Voltage Regulators that are capable of providing an output current that is in excess of 700mA with a maximum dropout voltage of 1.5 V at 700mA. This series contains six fixed output voltages of 1.2 V,1.8 V, 2.5V, 3.3 V, and 5.0 V that have no minimum load requirement to maintain regulation. Also included is an adjustable output version that can be programmed from 1.25 V to 20 V with two external resistors. On chip trimming adjusts the reference/output voltage to within %2B2 .0% accuracy Internal protection features consist of output current. limiting，safe operating area compensation, and thermal shutdown. The MET 1117 series can operate with up to 20 V input. Devices are available in SOT223，TO252-2L.

  Features

●Output Current in Excess of 700mA

●Dropout Voltage: 1.08V@ lout =100mA

●Operating Voltage Range: 4.8V~ 20V (MET1117A33 )

● Highly Accuracy: %2B2%

●Adjustable Output Voltage Option

● Standby Current: 3 .5mA (TPY.)

●High Ripple Rejection: 60dB@ 1KHz ( MET1117A33 )

●Line Regulation: 2mV (TYP.)

●Temperature Stability≤0. 5%

●Current Limit ( 850mA)

●Thermal Shutdown Protection ( 160C )

●Small Packages:SOT223、TO252-2L

  Typical Application

●Consumer and Industrial Equipment Point of Regulation

●Switching Power Supply Post Regulation

●Hard Drive Controllers

●Battery Chargers
