■ SPECIFICATIONS
Series       系列 SHS         STH
Category Temperature Range 16V ~ 100V: -40 ~ 85℃         16V ~ 100V: -40 ~ 105℃
 160V ~ 450V: -25 ~ 85℃         160V ~ 450V: -25 ~ 105℃
"Nominal Cap. Range
标称容量范围" 82 ~ 33,000μF         47 ~ 33,000μF
"Capacitance Tolerance
静电容量允许差" -20% ~ 20 % （-10 ~ 30 % ）         -20% ~ 20 % （20 ℃，120Hz）
Leakage Current  漏电流  I=0.02 CV or 3(μA) whichever is smaller, after 5 min
"Dissipation Factor(tanδ)
Low Temp. Impedance
Stability  at  120Hz 阻抗稳定性"  16 V ~ 100V : Dissipation factor at 20℃，120Hz shall not exceed the values
  given in the table of Standard Ratings  160V ~ 450V : ≤ 0.15

  W. V .   10 16 25 35 50 63 80 100 160 ~ 450
  Z(-25℃)/Z( 20℃)   4  3 3 2  2  4
  Z(-40℃)/Z( 20℃)   15  10 8 6  5  -

"High Temp. Load Test
高温负荷测试"   The following specifications shall be satisfied when the capacitors are restored to 20℃
  after the rated working voltage applied for 2,000 hours at 85℃ (SHH, at 105℃)
  Capacitance Change            … ≤ ±15% of the initial value
  Dissipation Factor                … ≤ 200% of the initial specified value
  DC Leakage Current           … ≤ the initial specified value
"High Temp. Non-Load Test
 高温，非负载测试"   The following specifications shall be satisfied when then capacitors are restored
  to 20℃ after exposing them at the rated 85℃ (SHH, at 105℃) for 1,000 hours
  without voltage applied to the capacitors for a minimum of 30 minutes, at least 24
  hours but not more than 48 hours before the measurements.
  Capacitance Change            ... ≤ ±20% of the initial value
  Dissipation  factor                 ... ≤ 150% of the initial specified value
  DC Leakage Current            ... ≤ the initial specified value
