OPERATION MODE
|
|
Independent
|
(0~30V/0~6A) x 2, (5V/3A Max.) x 1
|
|
Series
|
60V 6A
|
|
Parallel
|
30V 12A
|
|
5V FIXED OUTPUT
|
|
Line Regulation
|
<5mV
|
|
Load Regulation
|
<10mV
|
|
Ripple & Noise
|
<2mVrms
|
|
Voltage Accuracy
|
5V±0.25V
|
|
Output Current
|
3A
|
|
TRACKING OPERATION
|
|
Tracking Error
|
<0.5% + 10mV of the master
|
|
Series Regulation
|
<300mV
|
|
CONSTANT VOLTAGE OPERATION
|
|
Line Regulation
|
<0.01%+3mV
|
|
Load Regulation
|
<0.01% + 3mV (rating current<3A)
<0.02% + 5mV (rating current<10A)
|
|
Ripple & Noise
|
<1mVrms 5Hz ~ 1MHz
|
|
Current Output
|
<100μS ( 50% load change, minimum load 0.5A )
|
|
CONSTANT CURRENT OPERATION
|
|
Line Regulation
|
<0.2% + 3mA
|
|
Load Regulation
|
<0.2% + 3mA
|
|
Ripple & Noise
|
<3mArms
|
|
METER
|
|
Type
|
3 1/2 digit 0.5" LED display
|
|
Accuracy
|
±( 0.5% of rdg + 2 digits )
|
|
INSULATION
|
|
Chassis and Terminal
|
20MΩ or above (DC 500V)
|
|
Chassis and AC Cord
|
30MΩ or above (DC 500V)
|
|
POWER SOURCE
|
|
|
|
AC 100V/120V/220V/240V ±10%, 50/60Hz
|
|
ACCESSORIES
|
|
|
User manual x 1
Power cord x 1
Test lead GTL-104 x 2 (<10A), GTL-105 x 1(<3A)
European test lead GTL-204 x 2(<10A), GTL-203 x 1(<3A)
|
|
DIMENSIONS & WEIGHT
|
|
|
|
255(W) x 145(H) x 346(D)mm
Approx. 18.5kg
|
