金属
称重
是
IP68
导体
ZLZ1B
多晶
0.03(%F.S.)
0.02(%F.S.)
0.01(%F.S.)
0.01%F.S
力知
企业名:杭州力知电子技术有限公司
类型:生产企业
电话: 0571-82309265
手机:15957146348
联系人:周先生
邮箱:zlload@163.com
地址:浙江杭州萧山区闻堰镇王家里工业区
1.柱式结构,动态响应好
2.焊接密封结构,采用亚弧焊接
3.结构紧凑,过载能力强,安装使用简单
4.*护等级:IP68,可在恶劣环境下长时间工作
5.多用于电子汽车衡,动态轨道衡和高吨位料斗秤等称重衡器
Characteristic and application:
1.Column t*e,good dynamic response
2. Hermetical sealed structure,argon-arc welded
3. Compact structure,strong overload ability,easilyto install
4.Protectingcl*: IP68,working under comparatively adverse circumstance
5. Mainly used in electronic truck scale ,dynamic railroad scale and big capacity hopper scale,ect
外形及安装尺寸
ZLZ1B型称重传感器 材质:合金钢不锈钢
技术参数Technical specifications |
| 技术参数Technical specifications | ||
电气特性Electrical specifications | 负荷特性Charateristic specifications | |||
灵敏度Rated output(mv/v) | 2.0(1.75)&plu*n;0.01 | 额定载荷Rated capacity | 5 kg | |
*点输出Zero balance | &plu*n;1.0% FS | 综合精度Comprehensive precive | &plu*n;0.03%FS | |
输入电阻Input Risistance | 450&plu*n;15 | 非线性Nonlinearity | &plu*n;0.03%FS | |
输出电阻Output Risistance | 480&plu*n;2 | 重复性Repeatability | &plu*n;0.01%FS | |
*缘电阻Insulation Risistance | ≥5000MΩ | 滞后性Hysteresis | &plu*n;0.01%FS | |
推荐电压Recommendation excitation voltage | 10V(DC) | 蠕变Creep(30minutes) | &plu*n;0.01%FS | |
*大电压Max excitation voltage | 20V(DC) | 回*Returning to zero | &plu*n;0.01%FS | |
温度特性Temperature characterisitic | 机械特性Physical characteristic | |||
温度补偿范围Compensated temperature range | -10℃-70℃ | *载荷Safe loading range | 120%FS | |
工作温度范围Operating temperature | -20℃-70℃ | *限载荷Limiting load range | 150%FS | |
*点输出温度影响Temperature effect on zero | &plu*n;0.02%FS/10℃ | *护等级Protection rank | IP68 | |
灵敏度输出温度影响Temperature effect on output | &plu*n;0.02%FS/10℃ | 电缆长度Cable lenth | 5m |
电缆连接方式Cable color code :
Input: Red( ) Black(-) Output: Green( ) White(-)
输入:红( ) 黑(-) 输出:绿( ) 白(-)
