MATERIALS & FLESH/PLATED 1. HOUSING: HIGH TEMP.THERMOPLASTIC+GLASS FIBRE (UL94V-0).COLOR BLACK 2. TERMINAL: PHOSPHOR BRONZE PLATED: 8u〞GOLD ON CONTACT AREA. Min: 90u〞TIN/LEAD ON SOLDER TAILS. BASE: Min 40u〞NICKEL. 3. SHELL COVER: STAINLESS.PLATED PLATED: 5u〞GOLD ON CONTACT AREA. BASE: Min 40u〞NICKEL. SPECIFICATION 1. CURRENT RATING: 1AMP Max 2. CONTACT RESISTANCE: 50m Ohms Max. 3. INSULATION RESISTANCE: 1000M Ohms Min.AT 500V DC. 4. DIELECTRIC WITHSTANDING VOLTAGE: 250V(r.m.s)AC.for 1 Minute. 5. OPERATING TEMPERATURE: -400C to+850C 6. STORAGE ENVIRONMENT: +50C to+350C at Relative Humidity 50% to 70%

企业名：深圳市星光科技发展有限公司

类型：

电话： 86-0755-33815081

联系人： 余邦栋

地址：
