型号:1801 护套材质:PVC 材料形状:圆线 产品:UL
Cable P/N | Max. Freq. (GHz) | Cable OD (inches) | Bend Radius (inches) | Weight (lbs/100 ft.) | VP % | Time Delay (ns/ft.) |
1801 | 34 | 0.185 | 1 | 3.7 | 84 | 1.2 |
1803* | 34 | 0.26 | 3/4 | 5.6 | 84 | 1.2 |
* Cables with a 3 as the last di* are internally ruggedized cables and are capable of withstanding a crush resistance of at least 150 lbs/linear inch.
RF Leakage > 100dB TO 18 GHz Connector Loss: Connection T*e Straight Right Angle N, SMA, TNC 0.012*F 0.017*F * 3.5mm 0.01*F N/A Impedance 50 Ohms RF Leakage to 18Ghz -100 dB; 90 dB for single Shield Temperature Range -65°C to 135°C 200°C Assemblies on Request * -55°C to +85°C
200°C Assemblies not available for 3.5mm Connectors
VSWR: Assemblies Containing 2 Straight 1 Straight 2 Right Angle Connections 1 Right Angle Connections 18 GHz Assemblies 1.35 1.40 1.45 26.5 GHz Assemblies 1.35 N/A N/A
