品牌:SC 型号:SC877 批号:201003 封装:IC 营销方式:* 产品性质:* 处理信号:数字信号 制作工艺:半导体集成 导电类型:双*型 集成程度:小规模 工作温度:-40~85（℃）
SC877 八位计算器IC
The SC877 is a single chip CMOS LSI with 8-di* arithmetic operation, single memory extraction-of-square-root, percentage calculation and auto power off function, designed for FEM LCD operation with a 1.5V power supply or dual power supply.
l Four standard functions(＋，－，×，÷)
l Auto constant calculations (constant: multiplicand, divisor, addend and subtrahend).
l Square and reciprocal calculations.
l Mark-up and mark -down calculations.
l Extraction of square root.
l Percentage calculations.
l Chain multiplication and division.
l Power calculations.
l Rough estimate calculations.
l Clear key: ON/C, ON/CE, CE
l Single chip CMOS construction.
l Rollover capability.
l Floating decimal point.
l LCD direct drive.
l Overflow indication: E.
l Accumulating memory: M+, M-, RM, CM, RM/CM.
l Only bare chip available.
l On chip supply voltage limiter by application.
