General Description
The MSP6682 series are protection ICs for over-charge/discharge of rechargeable one-cell Lithium-ion (Li+) batteries by
CMOS process.
The MSP6682 series can detect over-charge/discharge of Li+ one-cell and excess load current, and further include a short
circuit protector for preventing large external short circuit current.
Each of these ICs is composed of three voltage detectors, a reference unit, a hysteresis circuit, and a short circuit protector.
When charging voltage crosses the detector threshold from a low value to a value higher than VDET1, the output of COUT pin,
the output of over-charge detector/VD1, switches to low level, charger's negative pin level. After detecting overcharge, the
VD1 can be reset and the output of COUT pin becomes "H" when the VDD voltage is coming down to a level lower than
“VDET1 – VHYS1", or when a charger is disconnected from the battery pack while the VDD level is in between “VDET1" and
“VDET1 – VHYS1" in the MSP6682 version.

可完全代用精工S8261的(G3G),需要和华瑞CEG8205A,配对出售!价格优惠,请及时联系!!!

企业名：深圳市新迅和电子有限公司

类型：贸易/代理/分销

电话： 075527839558

手机：18820461190
