C 2012 X7R 1E 105 K T XXXX
Dimensions L x W (mm)
Temperature Characteristic
Rated Voltage (DC)
Nominal Capacitance (pF)
Capacitance Tolerance
Packaging Style
Internal Codes
The capacitance is expressed in three di* codes
and in units of pico Farads (pF). The first and
second di*s identify the first and second significant
figures of the capacitance. The third di* identifies
the multiplier. R designates a decimal point.
US Catalog // C Series — General Application// Version A11
Temperature
Characteristics
Capacitance
Change
Temperature
Range
C0G 0&plu*n;30 ppm/ºC -55 to +125ºC
SL +350/-1000 ppm/ºC -25 to +85ºC
X5R &plu*n;15% -55 to +85ºC
X6S &plu*n;22% -55 to +105ºC
X7R &plu*n;15% -55 to +125ºC
X7S &plu*n;22% -55 to +125ºC
Y5V +22/-82% -30 to +85ºC
Voltage Code Voltage(DC)
0G 4V
0J 6.3V
1A 10V
Voltage Code Voltage(DC)
1C 16V
1E 25V
1H 50V
Capacitance Code Capacitance
0R5 0.5pF
010 1pF
102 1,000pF (1nF)
105 1,000,000pF (1μF)
Case Code Length Width
C0402 0.40&plu*n;0.02 0.20&plu*n;0.02
C0603 0.60&plu*n;0.03 0.30&plu*n;0.03
C1005 1.00 &plu*n; 0.05 0.50 &plu*n; 0.05
C1608 1.60 &plu*n; 0.10 0.80 &plu*n; 0.10
C2012 2.00 &plu*n; 0.20 1.25 &plu*n; 0.20
C3216 3.20 &plu*n; 0.20 1.60 &plu*n; 0.20
C3225 3.20 &plu*n; 0.40 2.50 &plu*n; 0.30
*532 4.50 &plu*n; 0.40 3.20 &plu*n; 0.40
C5750 5.70 &plu*n; 0.40 5.00 &plu*n; 0.40
T*e: C0402, C0603, C1005, C1608,
C2012, C3216, C3225, *532, C5750
L Body Length
W Body Width
T Body Height
B Terminal Width
Tolerance Code Tolerance
B &plu*n; 0.10pF
C &plu*n; 0.25pF
D &plu*n; 0.50pF
E &plu*n; 0.20pF
G &plu*n; 2%
J &plu*n; 5%
K &plu*n; 10%
M &plu*n; 20%
Z +80/-20%
