产品名称：BLACK BOX切换器ACU1006MRVA
型号：ACU1006MRVA
品牌：BLACK BOX

描述：BLACK BOX切换器ACU1006MRVA；BLACK BOX延长器ACU1006MRVA；BLACK BOX KVM延长器; ACU1006MRVA
Rackmount CAT5 KVM Extender Hubs with Serial and Bidirectional Stereo Audio
KVM serial and audio extensions up to 300 metres - plus dual-access and rackmount options!
Combines six extenders in one box.
Send keyboard, monitor, mouse, and serial and bidirectional stereo audio signals up to 300-m from a CPU or ServSwitch?.
Dual-access capability enables the connection of two KVM consoles to each CPU.
Saves money and space.
Fully adjustable video equalisation for the * possible video quality.
Hub and remote units feature built-in surge protection on the CAT5 link side.

规格：
Clamping Voltage - Up to 15 volts
Compatibility - Keyboard: PC/AT?, PS/2?;
Monitor: VGA, Super VGA, XGA;
Mouse: PS/2 mouse only (user)
Resolution (Maximum) -
ACUWREM: 1600 x 1200 @ 60 Hz: 50 m;
ACU1006MVRA: 1600 x 1200 @ 60 Hz: 50 m;
ACUVREM:
1600 x 1200 @ 60 Hz: 60 m;
1280 x 1024 @ 60 Hz: 90 m;
1024 x 768 @ 60 Hz: 300 m;
ACURA001/2/4A:
1600 x 1200 @ 60 Hz: 200 m;
1280 x 1024 @ 60 Hz: 300 m
Connectors - ACU1006VRA: (6) DB25 F, (12) 3.5-mm barrel jack, (6) DB9 F, (6) RJ-45 F;
ACU1006DVRA: (12) Mini DIN 6-pin (Mouse and Keyboard) and (6) HD15 F;
ACUWREM: (1) HD15 F, (1) RJ-45 F, (2) Mini DIN 6-pin, (2) 3.5-mm barrel jack;
ACU1006MVRA: (6) HD15 F, (6) RJ-45 F, (12) Mini DIN 6-pin, (12) 3.5-mm barrel jack;
ACUVREM: (1) HD15 F, (1) RJ-45 F, (2) Mini DIN 6-pin, (2) 3.5-mm barrel jack;
ACURA001A: (1) HD15 F, (1) RJ-45 F, (2) Mini DIN 6-pin, (2) 3.5-mm barrel jack;
ACURA002A: (2) HD15 F, (2) RJ-45 F, (2) Mini DIN 6-pin, (2) 3.5-mm barrel jack;
ACURA004A: (4) HD15 F, (4) RJ-45 F, (2) Mini DIN 6-pin, (2) 3.5-mm barrel jack
Power — Hubs: 100-240 VAC, 50-60 Hz, external, auto sensing, with IEC connector and power cord;
Remote Units: External power supply unit 100-240 VAC auto sensing (included)
Dimensions - ACU1006VRA: 4.4(H) x 48.3(W) x 11.4(D) cm;
ACU1006DVRA: 8.8(H) x 48.3(W) x 11.4(D) cm;
ACUWREM: 5.1(H) x 8.1(W) x 10.9(D) cm;
ACU1006MVRA: 4.4(H) x 44.2(W) x 11(D) cm;
ACUVREM: 9.9(H) x 19.8(W) x 3.6(D) cm;
ACURA001A, ACURA002A: 4.4(H) x 14(W) x 14.5(D) cm;
ACURA004A: 4.4(H) x 27.4(W) x 14.5(D) cm
