1.Material:
   Housing:PBT UL94V-0
   S*ple:LCP  COLOR:BLACK
   Contact:C5210R-EH,T=0.20mm
   Lock:SUS301R-H,T=0.40mm
   Shell: SUS304R-1/2H,T=0.20mm
  2.Finish:
    Contact: (SEE *TE7) AU Plating on contact area.
            100u"MIN. TIN Plating on solder tails area.
            80u"MIN. Ni Plating all over.

 3.Specification:
   3.1:Rating:
      Contact current:1.0A(2;3;4;6;7;9;10)p 1.8A(1;5;8)p.
   3.2:Electrical:
      Contact resistance(EIA-364-23):
           50mΩ MAX. at 20mV MAX, 100mA.
      Insulation resistance(EIA-364-21):
           1000MΩ MIN. at 500V DC for 1Minute.
      Dielectric withstanding voltang(EIA-364-20):
           500V/AC 1Minute.
   3.3:Environmental:
      Durability(EIA-364-09):
           10000 cycles Min, 200 cycles per hour
 4.DIM. with mark"  "must be controlled by FAI.
 5.DIM. with mark"  "must be controlled by QC.
 6.The product accords with ROHS's standards
