是
整流管
否
PN
FM4007 FM4001
硅(Si)
IF=1.0A VB大于1000
标准整流二*管
企业名：湖北烨和电子科技有限公司
类型：生产企业
电话： 8607124767777
联系人：周慧
地址：湖北
| SY*OL | FM4001-M | FM4002-M | FM4003-M | FM4004-M | FM4005-M | FM4006-M | FM4007 -M | UNITS |
*大峰值反向电压 MaximumCurrent PeakReverse Voltage | VRRM | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | Volts |
*大反向*电压 Maximum RMS Voltage | VRMS | 35 | 70 | 140 | 280 | 420 | 560 | 700 | Volts |
*大直流阻断电压 Maximum DC Blocking Voltage | VDC | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | Volts |
*大正向平均整流电流TA=75℃ Maximum Average Forward Rectified Current | I(*) | 1.0 | Amps | ||||||
正向峰值浪涌电流 Peak Forward Surge Current Single Sine-wave on Rated Load (JEDEC Method) | IFSM | 30.0 | Amps | ||||||
1.0A直流电时*大*电压降 Maximum Instantaneous Forward Voltage Drop at 1.0A DC | VF | 1.1 | Volts | ||||||
*大反向漏电流 Maximum DC Reverse Current TA=25℃ at Rated DC Blocking Voltage TA=100℃ | IR | 5.0 50.0 | uA | ||||||
典型结电容 T*ical Junction Capacitance (*TE 1) | CJ | 15 | pF | ||||||
典型热阻 T*ical temperature Resistance (*TE 2) | RθJA | 60 | ℃/W | ||||||
工作温度存储温度 OperatingANDStorageTemperature Range | TJ/TSTG | -65 to +150 | ℃ | ||||||
