在线询价：
是
快恢复二*管
否
PN
SF36G SF35G SF34G SF33G
硅(Si)
IF=3.0A VB大于400V
*快恢复二*管。
企业名：湖北烨和电子科技有限公司
类型：生产企业
电话： 8607124767777
联系人：周慧
地址：湖北
| SY*OL | SF 31G | SF 32G | SF 33G | SF 34G | SF 35G | SF 36G | UNITS | |
*大峰值反向电压 MaximumCurrent PeakReverse Voltage | VRRM | 50 | 100 | 150 | 200 | 300 | 400 | Volts | |
*大反向*电压 Maximum RMS Voltage | VRMS | 35 | 70 | 105 | 140 | 210 | 280 | Volts | |
*大直流阻断电压 Maximum DC Blocking Voltage | VDC | 50 | 100 | 150 | 200 | 300 | 400 | Volts | |
*大正向平均整流电流TL=55℃ Maximum Average Forward Rectified Current
| I(*) | 3.0 | Amps | ||||||
正向峰值浪涌电流 Peak Forward Surge Current 8.3ms Single Sine-wave on Rated Load (JEDEC Method) | IFSM | 125.0 | Amps | ||||||
3A直流电时*大正向*电压降 Maximum Instantaneous Forward Voltage Drop at3.0A DC | VF | 0.95 | 1.25 | Volts | |||||
*大反向漏电流 Maximum DC Reverse Current TA=25℃ at Rated DC Blocking Voltage TA=100℃ | IR | 5.0 100 | uA | ||||||
典型热阻 T*ical Thermal Resistance (*TE 1) | RθJA | 35.0 | ℃/W | ||||||
典型结电容 T*ical Junction Capacitance (*TE 2) | CJ | 80.0 | 60.0 | pF | |||||
*大反向恢复时间 Maximum Reverse Recovery Time(*TE 3) | Trr | 35 | ns | ||||||
工作温度存储温度 Operating AND Storage Temperature Range | TSTG/TJ | -55 to +150 | ℃ | ||||||
