在线询价：
是
整流管
否
PN
HA2A HA2D HA2G HA2K
硅(Si)
IF=2.0A VB大于800V
整流二*管
企业名：湖北烨和电子科技有限公司
类型：生产企业
电话： 8607124767777
联系人：周慧
地址：湖北
| SY*OL | HA2A | HA2B | HA2D | HA2G | HA2J | HA2K | UNITS | |
*大峰值反向电压 Maximum current Peak Reverse Voltage | VRRM | 50 | 100 | 200 | 400 | 600 | 800 | Volts | |
*大反向*电流 Maximum RMS Voltage | VRMS | 35 | 70 | 140 | 280 | 420 | 560 | Volts | |
*大直流阻断电压 Maximum DC Blocking Voltage | VDC | 50 | 100 | 200 | 400 | 600 | 800 | Volts | |
*大正向平均整流电流TT=110℃ Maximum Average Forward Rectified Current | I(*) | 2.0 | Amps | ||||||
正向峰值浪涌电流 Peak Forward Surge Current, 8.3 ms Single Half Sine-wave Superimposed on Rated Load (JEDEC Method) | IFSM | 50 | Amps | ||||||
2.0A直流电时*大正向*电压降 Maximum Instantaneous Forward Voltage @ 2.0A | VF | 1.0 | 1.3 | 1.7 | Volts | ||||
*大反向漏电流 Maximum DC Reverse Current @ TA=25℃ at Rated DC Blocking Voltage @ TA=125℃ | IR | 5.0 200.0 | uA | ||||||
*大逆向恢复时间 Maximum Reverse Recovery Time ( Note 1 ) | Trr | 50 | 75 | nS | |||||
典型结电容 T*ical Junction Capacitance ( Note 2 ) | CJ | 17.0 | pF | ||||||
典型热阻 T*ical Thermal Resistance( Note 3) | RΘJL | 30.0 | ℃/W | ||||||
工作温度存储温度 Operating AND Storage Temperature Range | TJ/TSTG | -55 to +150 | ℃ | ||||||
