Unit:mm TYPE | A | B | C | D | URB3D16 | 4.1 Max. | 1.8 Max. | 4.15 Max. | 1.15 Max. | URB4D18 | 5.0 Max. | 2.0 Max. | 6.9 Max. | 1.5 Max. | URB4D28 | 5.0 Max. | 3.0 Max. | 6.9 Max. | 1.5 Max. | URB5D18 | 6.0 Max. | 2.0 Max. | 8.2 Max. | 2.0 Max. | URB5D28 | 6.0 Max. | 3.0 Max. | 8.2 Max. | 2.0 Max. | URB6D28 | 7.0 Max. | 3.0 Max. | 9.5 Max. | 2.0 Max. | URB6D38 | 7.0 Max. | 4.0 Max. | 9.5 Max. | 2.0 Max. |
Test Equipment and Conditions ▲ Inductance is measured with LCZ-1062 LCR Meter or equivalent. ▲ Maximum allowable DC current is that which causes a 10% inductance reduction of the initialvalue,or coil temperature to rese by 40℃,whichever is *aller.(Reference ambient temperature 20℃) ▲ Operating temperature:-25℃～ 85℃ Features ▲ Low profile and square. ▲ Magnetically shielded and low DC resistance. ▲ Suitable for large currents. ▲ Excellent solderability and high heat resistance. ▲ Low cost and packed in embossed carrier tape. Applications ▲ Ideal use in notebook, hard disk,DC/DC converters,di*al camera, LCD television set, and other electronic equipment. |
