品牌:L*A 型号:SM-170 类型:LCD触摸屏 屏幕类型:液晶 屏幕尺寸:17(寸) 分辨率:1280x1204 亮度:250(cd/㎡) 对比度:450 : 1 用途:后台管理系统、收银、点餐、 接口:15 injection VGA 尺寸:33.8x 27.0(cm)
*产品稳定*
*接口丰富,扩展*
*采用5线电阻式触摸屏
*体积小巧,结构紧凑,节省空间
*底座稳固,*合人体工程学,操作便捷
*外观时尚,做工细腻,为店铺增光添彩
Specification | SM-170 |
Max resolution | 1280x1204 |
LCD size | 17” |
Display area(mm) | 338(w) x 270(h) |
Color | 16.70 mega pixel |
Brightness | 250 cd/m2 |
Contrast ratio | 450 : 1 |
Interface | 15 injection VGA |
Power supply | 12V external output power supply, 3 amp |
Color- Face | Black, or Silver |
Total size : | 418 x 378 x 226mm |
temperature | 0 to 40 degree C |
Humidity | 10% to 90% |
Touch panel | 5 wire resistive RS232 or U* |
Touch panel Detail Specification: | Functions even if damaged, Narrow border design Capable of Writing and Signature Capture Linearity 1.5% or less, Insulation 20 Megaohms or greater / 25V (DC) Optical : Tran*ittance 82% +-5% Mechanical : Activation Force 50g or less Durability : Finger Touch 35M touches ,Pen Hitting 100M touches Surface Hardness 3H or greater (JIS K5400) |
Operating System | Windows 95/98/2000/ME/XP/NT/CE, DOS, Linux, Mac |
![]() | ![]() |
|
