品牌:GS 型号:电位器R1640G-A8 种类:双联 用途:微调 材料:碳膜 性能:微调 阻值调节方式:旋转式 阻值变化方式:X式(直线式) 标称阻值:10K-500K 额定功率:0.125(W) 阻值允许偏差:&plu*n;20(%) 滑动噪声:-(V) 分辨率:-(%) *位电阻:-(Ω) 接触电阻:-(Ω) *缘电阻:100(MΩ) *合度:ROHS
精耀GS B200K旋转式电位器R1640G-A8
Mechanical characteristics机械特性: | |
Total rotational angle 全回转角度 | 300 degrees &plu*n;5 degrees |
Rotational torque 回转力度 | 2~20mN.m(20 to 200gf.cm) |
Rotation s*per strength 止回转角度 | 0.7N.m(7kgf.cm) |
Push pull strength 轴推拉强度 | 70N(7kgf) |
Click position C.C.位子 | Center,11,21,31,41 detent |
Electrical characteristics电器特性: | |
Total resistance 总阻值 | 5KΩ~2MΩ |
Total resistance tolerance 总阻值允许差 | &plu*n;20% (more then 1 MΩ&plu*n;30%) |
Rated power 定格电力 | curve B:0.125W , other then B:0.06W |
Max. operating voltage *高使用电压 | curve B:200VAC , other then B:150VAC |
Resistance taper 阻值线性 | A,B,C |
Slide noise 滑动噪音 | less than 47mv |
Residual resistance 残留阻值 | R≥250 KΩ 0.01% max. of total resistance 250 KΩ>R>10 KΩ 20Ω max. 10 KΩ≥R 10 Ω max. |
Insulation resistance *缘* | more than 100MΩ at 500VDC |
Tracking 相互偏差 | -40 to 0db≤3db |
Rotational life 回转寿命 | 15000 cycles |
For more information, visit our website or contact our head office 为获得更多的信息,请联系我们,或者参考我们的网站 |
