HS型 恒温恒湿箱 |
|
HS Series Constant Temperature &Humidity Chamber |
|
一.恒温恒湿箱,恒温恒湿试验箱,可程式恒温恒湿试验箱用途概述 |
|
广泛用于*、纺织、食品*、生物工程等试验和工业产品各项温湿度测试。 |
|
二．恒温恒湿箱,恒温恒湿试验箱,可程式恒温恒湿试验箱产品特点： |
|
1、采用镜面不锈钢内胆，四周半圆弧易于清洁，箱内搁板间距可调。 |
|
2、采用双重门结构，隔热性能好。内门采用全钢化玻璃门，打开外门，观察内情况时不影响箱内温度。 |
|
3、*、大容量湿度发生器。*湿度控制发生快、精度高、波动小。 |
|
4、原装法国“泰康”全封闭压缩机，配置*启动。高、低压力多重保护。 |
|
I.Applications: |
|
|
|
It is applicable to humidity testing in the medicinal, spin, food and biology and so on. |
|
II.Feature: |
|
1.Shelves inside the chamber are easy to detach and convenient to wash ,the henght of each shelf can also be adjusted. |
|
2.There is a layer of toughtoned-gl* offr with sealing rubber as the inner lay of the outer door for convenient observation of the in-incubator temperature. |
|
3.High precision and large capacity humidity apparatus, which be sure the humidity quickly and low wave. |
|
4.Compressor from French “TaiKang” .which is whole closed .The system was equipped with the function of delay-start and high/low pressure protection |
|
三．恒温恒湿箱,恒温恒湿试验箱,可程式恒温恒湿试验箱技术参数/(Speclifucations) |
|
型号Model |
SHS-100 |
SHS-150 |
SHS-250 |
SHS-500 |
|
电源电压 Mains voltage |
220V, 50Hz |
|
控温范围Temperature control range |
-70~150 ℃(可按客户要求定做） |
|
温度波动Temperature fluctuation |
≤±0.5 ℃ |
|
控湿范围Humidity control range |
30~95%RH |
|
湿度波动Humidity fluctuation |
≤±2%RH |
|
消耗功率Consumption power |
1400W |
1500W |
1800W |
2250W |
|
工作室尺寸mm/(W.D.H) Dimensions |
500 × 400 × 500 |
500 × 500 × 600 |
520 × 630 × 780 |
700 × 800 × 900 |
|
外箱尺寸mm/(W.D.H) Dimensions |
1050 × 900 ×1520 |
1050 × 1000 ×1620 |
1070 ×1130 ×1190 |
1250 × 1300 × 2020 |
恒温恒湿箱,恒温恒湿试验箱,可程式恒温恒湿试验箱 |
|
|
|
（本产品整机包修一年） |
