是
整流管
否
PN
MR760 MR756 MR750
硅(Si)
IF正向直流电流6A 反向击穿电压大于1000V
整流二*管
企业名：湖北烨和电子科技有限公司
类型：生产企业
电话： 8607124767777
联系人：周慧
地址：湖北
|
SY*OL |
| MR750 | MR751 | MR754 | MR756 | MR760 |
|
UNITS |
*大峰值反向電壓 Maximum recurrent reverse voltage |
VRRM |
50 |
100 |
400 |
600 |
1000 |
Volts | ||
*大RMS輸入電壓 Maximum RMS voltage |
VRMS |
35 |
70 |
280 |
420 |
700 |
Volts | ||
*大直流阻斷電壓 Maximum DC blocking voltage |
VDC |
60 |
120 |
480 |
700 |
1200 |
Volts | ||
*大平均正向整流電流 Maximum average forward rectified current at Tc=60℃ |
I(AV) |
6 |
Amps | ||||||
正向峰值浪涌電流 Peak forward surge current single sine-wave on rated load (JEDEC Method) |
IFSM |
400 |
Amps | ||||||
6A時*大正向瞬間電壓降 Maximum instantaneous forward voltage drop at6A,Tj=25℃ |
VF |
0.9 |
Volts | ||||||
*大反向漏電流 Maximum DC reverse current TA=25℃ at rated DC blocking voltage TA=100℃ |
IR |
5.0 100.0 |
μA | ||||||
工作溫度和存儲溫度 Operating and Storage Temperature Range | TJ TSTG |
-55 TO +150 | ℃ | ||||||
提供大量*比MR750 MR751 MR752 MR754 MR756 MR760 整流二*管.
