是
整流管
否
PN
SOZA CELL 50 AMP
硅(Si)
IF=50A VB大于600V
大功率整流二*管
企业名：湖北烨和电子科技有限公司
类型：生产企业
电话： 8607124767777
联系人：周慧
地址：湖北
大量供应铜CELL 25A/35A/50A/70A 规格 STD 、TVS 整流二*管。
| SY*OL | SC |
UNITS | ||||
50A | 50B | 50D | 50G | 50J | |||
*大峰值反向电压 Maximum current Peak Reverse Voltage | VRRM | 50 | 100 | 200 | 400 | 600 | Volts |
*大反向*电流 Maximum RMS Voltage | VRMS | 35 | 70 | 140 | 280 | 420 | Volts |
*大直流阻断电压 Maximum DC Blocking Voltage | VDC | 50 | 100 | 200 | 400 | 600 | Volts |
*大正向平均整流电流TT=125℃ Maximum Average Forward Rectified Current | I(*) | 50 | Amps | ||||
正向峰值浪涌电流 Peak Forward Surge Current, 8.3 ms Single Half Sine-wave Superimposed on Rated Load (JEDEC Method) | IFSM | 500 | Amps | ||||
50A直流电时*大正向*电压降 Maximum Instantaneous Forward Voltage @50A | VF | 1.1 | Volts | ||||
*大反向漏电流 Maximum DC Reverse Current @ TA=25℃ at Rated DC Blocking Voltage @ TA=125℃ | IR | 5.0 500.0 | uA | ||||
典型结电容 T*ical Junction Capacitance | CJ | 350 | pF | ||||
典型热阻 T*ical Thermal Resistance | RΘJA | 1.0 | ℃/W | ||||
工作温度存储温度 Operating AND Storage Temperature Range | TJ/TSTG | -55 to +150 | ℃ | ||||
