技术参数Technical specifications

技术参数Technical specifications

电气特性Electrical specifications

负荷特性Charateristic specifications

灵敏度Rated output（mv/v）

1.0~2&plu*n;0.02

额定载荷Rated capacity

1kg

*点输出Zero balance

&plu*n;1.0% FS

综合精度Comprehensive precive

&plu*n;0.05%FS

输入电阻Input Risistance

385&plu*n;15

非线性Nonlinearity

&plu*n;0.05%FS

输出电阻Output Risistance

350&plu*n;2

重复性Repeatability

&plu*n;0.03%FS

*缘电阻Insulation Risistance

≥5000MΩ

滞后性Hysteresis

&plu*n;0.03%FS

推荐电压Recommendation excitation voltage

10V(DC)

蠕变Creep(30minutes)

&plu*n;0.05%FS

*大电压Max excitation voltage

15V(DC)

回*Returning to zero

&plu*n;0.01%FS

温度特性Temperature characterisitic

机械特性Physical characteristic

温度补偿范围Compensated temperature range

-20℃-70℃

*载荷Safe loading range

120%FS

工作温度范围Operating temperature

-10℃-60℃

  *限载荷Limiting load range

150%FS

*点输出温度影响Temperature effect on zero

&plu*n;0.02%FS/10℃

*护等级Protection rank

IP67

灵敏度输出温度影响Temperature effect on output

&plu*n;0.02%FS/10℃

电缆长度Cable lenth

0.5m
