在线询价：
是
整流管
否
PN
*整流管HER307 HER301
硅(Si)
IF=3.0A VB大于1000V
*整流二*管
企业名：湖北烨和电子科技有限公司
类型：生产企业
电话： 8607124767777
联系人：周慧
地址：湖北
| SY*OL | HER | UNITS | |||||||||
301G | 302G | 303G | 304G | 305G | 306G | 307G | ||||||
*大峰值反向电压 MaximumCurrent PeakReverse Voltage | VRRM | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | Volts | |||
*大反向*电压 Maximum RMS Voltage | VRMS | 35 | 70 | 140 | 280 | 420 | 560 | 700 | Volts | |||
*大直流阻断电压 Maximum DC Blocking Voltage | VDC | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | Volts | |||
*大正向平均整流电流TL=55℃ Maximum Average Forward Rectified Current
| I(*) | 3.0 | Amps | |||||||||
正向峰值浪涌电流 Peak Forward Surge Current 8.3ms Single Sine-wave on Rated Load (JEDEC Method) | IFSM | 150.0 | Amps | |||||||||
3.0A直流电时*大正向*电压降 Maximum Instantaneous Forward Voltage Drop at3.0A DC | VF | 1.0 | 1.3 | 1.7 | Volts | |||||||
*大反向漏电流 Maximum DC Reverse Current TA=25℃ at Rated DC Blocking Voltage TA=100℃ | IR | 10 200 | uA | |||||||||
典型热阻 T*ical Thermal Resistance (*TE 1) | RθJA RθJL | 35 10 | ℃/W | |||||||||
典型结节电容 T*ical Junction Capacitance (*TE 2) | CJ | 60 | 35 | pF | ||||||||
*大反向恢复时间 Maximum Reverse Recovery Time(*TE 3) | Trr | 50 | 75 | ns | ||||||||
工作温度存储温度 Operating AND Storage Temperature Range | TSTG/TJ | -55 to +150 | ℃ | |||||||||
