品牌:ST 型号:STD150NH02L 批号:10+ 封装:TO-252 营销方式:* 产品性质:新品 处理信号:模拟信号 制作工艺:半导体集成 导电类型:双*型 集成程度:小规模 规格尺寸:6.4×6（mm） 工作温度:-55 to 175（℃） 静态功耗:125（mW） 类型:其他IC
型号：STD150NH02L （N-CHANNEL 24V - 0.003 W - 150A ClipPAK™/IPAK STripFET™ III POWER MOSFET）
厂家：ST
封装：TO-252
数量：750000
TYPE VDSS RDS(on) ID
STD150NH02L 24 V < 0.0035 W 150 A
n TYPICAL RDS(on) = 0.003 W @ 10 V
n TYPICAL RDS(on) = 0.005 W @ 5 V
n RDS(ON) * Qg INDUSTRY’s BENCHMARK
n CONDU*ION LOSS* REDUCED
n SWITCHING LOSS* REDUCED
n LOW THR*HOLD DEVICE
n THROUGH-HOLE IPAK (TO-251) POWER
PACKAGE IN TUBE (SUFFIX “-1")
n SURFACE-MOUNTING POWER PACKAGE
IN TAPE & REEL (SUFFIX “T4”)
D*CRIPTION
The STD150NH02L utilizes the latest advanced design
rules of ST’s proprietary STripFET™ technology. This
novel 0.6m process utilizes also unique metallization
techniques that couple to a "bondless" *embly
technique result in outstanding performance with
standard DPAK outline. It is therefore ideal in high
performance DC-DC converter applications where
efficiency it to be achieved at very high out currents.
APPLICATIONS
n SPECIFICALLY D*IGNED AND OPTIMISED
FOR HIGH EFFICIENCY DC/DC CONVERT*
