Description

• MOSFET, P, LOGIC, SO-8
• Transistor Polarity:P
• Max Current Id:-6.7A
• Max Voltage Vds:20V
• On State Resistance:0.04ohm
• Rds Measurement Voltage:-4.5V
• Max Voltage Vgs:-700mV
• Power Dissipation:1.6W
• Transistor Case Style:SOIC
• No. of Pins:8
• Case Style:SOIC
• Cont Current Id:5.3A
• Current Temperature:25°C
• External Depth:5.2mm
• External Length / Height:1.75mm
• External Width:4.05mm
• Full Power Rating Temperature:25°C
• No. of Transistors:1
• Pin Configuration:b
• Pin Format:1 S
• 2 S
• 3 S
• 4 G
• 5 D
• 6 D
• 7 D
• 8 D
• Power Dissipation Pd:1.6W
• Pulse Current Idm:21A
• Row Pitch:6.3mm
• SMD Marking:F7404
• Termination T*e:SMD
• Transistor T*e:MOSFET
• T* Voltage Vds:-20V
• T* Voltage Vgs th:-0.7V
• Voltage Vgs Rds on Measurement:-4.5V
