LC光衰减器衰减器价格光衰减器厂家-深圳科海

型号/规格：
LC
品牌/商标：
科海

Description MPO Loopback is used for network, or optical link test, all 40/100G network. The MPO Loopback which strictly complies with the RoHS, not only meets the criteria of both TIA/EIA 604-5 and IEC 61754-7, but also provides compacted spec for a test of Burn in and network component. Applications ● Small / Compact Housing Design ● QSFP Available ● RoHS Compliant Features ●DataCenterInfrastructure ● Parallel Optics ● Storage Area Network and Fiber Channel ● 40G and 100Gbps Protocols Specifications Parameter Conditions Operation Wavelength 1310/1550nm Attenuation Tolerance ±1dB( at 2-10dB), ±10%( at 11-20dB) Return Loss 60dB(8°Polishing) Operating Temperature 0~75℃ Attenuation 1~20dB(SM 1310/1550 nm) Housing Dimension Height 5.9 mm/Length 25.3mm/Width 16.2mm

了解详情立即询价
